Evolution Atlas Skid Plate For Beetle, Golf & Jetta IV with OIl Drain Hole Provison

A3002
Shipping: This product ships from our Canadian Warehouse via Canadian Post shipping. A $30 "handling fee" will be added during checkout and work as a discounted shipping fee. Free shipping does not apply to this product and delivery time runs between 7-10 business days
Pricing: $269.00

Customize Your Item

- Oil Drain Cover -
 * required
Qty:

Description

PLEASE NOTE--- NEW REVISION FOR ATLAS SKID PLATES PERTAINING TO TDIS

This kit now requires an OIL DRAIN COVER to be used with the TDIs. It contains a 98% Cut-Out for the Oil Drain Cover that needs to be removed to install the Drain Cover.





Fits:

1998-2010 New Beetle (All engines except 2.5L)
1999.5-2006 Golf (All engines)
1999.5-2005 Jetta (All engines)
1999.5-2006 Jetta Wagon (All engines)
2004 Golf R32
All 2.0 City Golf & Jettas (Canada)
Installed Perfectly On A 2005 Beetle GLS Convertible



A great choice for the everyday urban driver guaranteed to provide the ultimate in protection for your oil pan.

Volkswagen's oil pans are made of paper-thin cast aluminum that is easily cracked by many objects such as road debris, manhole covers, and speed bumps. While your car may be at stock height, there is only approximately 4 inches of ground clearance with your oil pan. If you are lowered from stock height, there is very little room for error when negotiating an object in your path. Here is some information on this Evolution Aluminum Skid Plate for those of you who haven't seen it before.

  • The plate is 5052 grade aluminum and is 4.8mm (.191 inches) thick.
  • Two Strengthening Ribs have been pressed into the plate thus doubling the strength of the skid plate.
  • Protects your car's oil pan, a/c pump, radiator, transmission, and plastic side skirts.
  • 98% cut oil hole for TDI's, you finish the cuts and can order the bolt on cover
  • Bolts to the frame with 6 steel rivet-nuts.
  • Never rusts.
  • Weighs 17 pounds (21.3 including hardware).
  • The maximum amount of ground clearance possible provided.
  • One hour install.
  • The most user friendly rivet-nut installation tool comes with every kit.
  • Easy one minute modification to your plastic side skirts.
  • Our kit comes with two 10 gauge powder coated steel front mounting brackets.
  • The skid plate also acts as a stress bar at the rear for improved handling and has open slot holes at the back for easy installation.
  • Comes with two insulating washers to act as a barrier preventing electrolysis.
  • Shipped to your doorstep in a box as a complete kit. No other attachments need to be purchased.
  • Draft/Design by: EVOLUTION IMPORT INC.
  • CNC Machine Manufactured.
